Application B — Document

Technical data sheet

Wet ESP Systems, laid out as an editable Word document: named styles, real tables, one conceptual schematic — and nothing AHLS has not published.

Page 1Rendered by Microsoft Word from the DOCX

How the sheet works

A
Title block first. Document number, revision and status — the same block that closes every web page and slide. Prepared / checked / approved are left for AHLS.
B
Published figures only. Up to 99% and < 10 mg/Nm³ are quoted from the AHLS Wet ESP page, with the source stated under the figures.
C
One conceptual schematic. SVG with PNG fallback, flagged “to be verified by AHLS engineering”. Its legend is an editable table, not text inside the picture.
D
Grey means unknown. Gas flow, temperature, pressure drop, dimensions and codes are not published, so they stay as visible placeholders — never estimated.
E
Built on styles. Title, Heading 1, AHLS Lead, Caption and AHLS Note live in Word’s Styles pane; numbering uses a real list definition.

Previews on this page are the pages Word produced when the file was opened and exported — not a separate mock-up.

The same data, readable on any screen.

The technical table in the document, rendered as accessible HTML from the same content file.

Wet ESP technical data: parameter, value, unit and status
Parameter	Value	Unit	Status
Performance
Collection efficiency	Up to 99	%	Published
Outlet loading	< 10	mg/Nm³	Published
Target pollutants	Sub-micron particulate, fumes, condensable organic aerosols, acid mist	—	Published
Design
Electrode configuration	Proprietary disk-in-tube	—	Published
Power supply	High frequency	—	Published
Gas flow arrangement	Upflow or downflow inlet, per waste stream	—	Published
Internal materials	Stainless steel on all internal surfaces; higher alloys available	—	Published
Construction	Heavy-duty, modular	—	Published
Process data
Design gas flow	[To be confirmed by AHLS engineering]	Nm³/h	To confirm
Inlet gas temperature	[To be confirmed by AHLS engineering]	°C	To confirm
Inlet particulate loading	[To be confirmed by AHLS engineering]	mg/Nm³	To confirm
Pressure drop	[To be confirmed by AHLS engineering]	kPa	To confirm
Equipment
Number of collecting tubes / fields	[To be confirmed by AHLS engineering]	—	To confirm
Power supply rating	[To be confirmed by AHLS engineering]	kV / mA	To confirm
Wash water requirement	[To be confirmed by AHLS engineering]	m³/h	To confirm
Overall dimensions (L × W × H)	[To be confirmed by AHLS engineering]	m	To confirm
Design codes & standards	[To be confirmed by AHLS engineering]	—	To confirm
